Swisstrax® Portable Dance Floor Kits

Swisstrax® Portable Dance Floor Kits are the perfect easy-install dance flooring for any practice space or special event. These highly portable dance floor kits can be quickly assembled in minutes without tools or glue, and easily disassembled for travel or storage.  Swisstrax® dance floor tiles are ideal for every dance type, from ballet, jazz, tap, Irish step, Flamenco and more.  Available in several luxurious wood grain patterns, these tightly interlocking, UV stabilized vinyl-top dance floor tiles will create the perfect durable dance flooring for your home dance studio, yoga studio, wedding, or special event. Swiss designed and made in the USA, Swisstrax® is proud to deliver top quality modular flooring products made with exacting technology and manufacturing standards, and the highest quality materials available. Swisstrax® Portable Dance Floor Kits are a suspended modular flooring solution built to protect from wear-and-tear to your original flooring, and backed by a 15 year limited lifetime warranty.

Material:  Manufactured with high-grade polypropylene and a vinyl top surface.

Edging Colors:

• Oak Parquet: Jet Black edging.
• Reclaimed Pine: Slate Grey edging.
• Ash Pine: Pearl Grey edging.

Tile Size: 12" x 12".

Thickness : 1/2".

Weight : 2 lbs. per tile.

Shoe Style: -All shoe styles, hard or soft.

Tensile Strength: 1,250 PSI

Recommended Dance Floor Kit Sizes:  Rule of thumb: 9 sq ft per couple.

• 3' x 3' - Personal practice dance floor.

• 5' x 5' - Personal practice dance floor, yoga floor, and aerobic exercise floor
• 8' x 8': Dance floor and event floor for up to 7 couples.

Kit Contents:

• 3' x 3' Kit - Contains 9 tiles, 12 edge pieces, & 4 corner pieces
• 4' x 4' Kit - Contains 16 tiles and 16 edge pieces, & 4 corner pieces
• 5' x 5' Kit - Contains 25 tiles and 20 edge pieces, & 4 corner pieces
• 6' x 6' Kit - Contains 36 tiles and 24 edge pieces, & 4 corner pieces
• 7' x 7' Kit - Contains 49 tiles and 28 edge pieces, & 4 corner pieces
• 8' x 8' Kit - Contains 64 tiles and 32 edge pieces, & 4 corner pieces
• 9' x 9' Kit - Contains 81 tiles and 36 edge pieces, & 4 corner pieces
• 10' x 10' Kit - Contains 100 tiles and 40 edge pieces, & 4 corner pieces.

• Surface Prep: You must clean your subfloor so that it is free of all dirt, dust, grease, or other foreign material before beginning installation.
• We will start at the top left corner of your designated dance area. Put a tile down with the male edges (no loop) facing towards the top and left direction. Make sure the female sides (loops) of the tile are facing the bottom and right direction.
• Attach your second tile to the right side of the first tile, lowering and interlocking it into each loop.
• Repeat step #2 until you have completed one full side of your dance floor.
• Once you’ve secured your last tile into place in the first row, you’ll begin a second row beneath the very first tile you started with. Interlock the top of your second row tile with the bottom of your first row tile. Follow step #2.
• Follow the same process to fill in all of your rows of tiles to create your full dance floor size.
• Once the tiles are in place, you can snap in the edge pieces, if you purchased them. Start with the male edges. Lay them out to be sure you have enough before clicking them into place as shown in the step #6 diagram.
• As you did with the male edges, lay out all female edges to make sure you have enough. Once you are ready you can click the female edges into place to complete your floor.
• **For wall to wall installations: When you come up to a wall or object, don’t worry. Simply measure the area and cut the tiles with a tile cutter or a power saw with a fine-toothed blade. Interlock the trimmed tiles into place. When trimming the tiles into place, make sure you leave about a 3/4” space between the tiles and the wall or obstruction. Once the tiles are in place, you can then snap in the edge pieces if you purchased them.

• Vacuuming or sweeping any loose crumbs, dust, or debris from the modular tiles when necessary.
• Hose off or damp mop the floor tiles with a mild soap and water mixture for tough or caked on dirt and/or stains.
