Diamond Flex Garage Floor Tiles – Interlocking Design (23.35 sqft/Case)
- Made In USA
- Car Jack Approved
- Easy to Clean
- DIY Friendly
Financing available — pay over time. Learn more
Free Shipping
Ships between Apr 15 – Jul 12
- Car & Jack Approved
- Chemical Resistant
- Colorfast
- Made In USA
- Car Jack Approved
- Easy to Clean
- DIY Friendly
Enter your room to see how many cases you need. Each case holds 8 tiles. No extra is added — tick the box above to allow for cuts and pattern matching.
Best Selling in Garage Tiles
Flex Nitro Garage Floor Tiles XL - 20.5" x 20.5"
Rated 4.8 out of 5 from 216 reviews4.8
Starting From:
$3.25/sqft
$5.00Save 35%Turbo Tile Diamond Garage Floor Tiles - Ultra XL - 17" x 17" (2 sqft/tile)
Rated 5.0 out of 5 from 1 review5.0
Starting From:
$3.03/sqft
$4.66Save 35%
You May Also Like
Swisstrax Ribtrax Pro Garage Floor Tiles - 15.75" x 15.75"
Rated 5.0 out of 5 from 26 reviews5.0
Starting From:
$5.10/sqft
$6.80Save 25%6.5mm XL Diamond Flex PVC Garage Floor Tiles (18" x 18") - Hidden Interlock
Starting From:
$8.80/sqft
$11.73Save 25%Swisstrax Ribtrax Pro Smooth Garage Floor Tiles - 15.75" x 15.75"
Rated 5.0 out of 5 from 2 reviews5.0
Starting From:
$4.98/sqft
You May Also Need
Everything else for a complete install.
Details & Specifications
Dimensions
- Exact Weight (lbs)
- 27
- Size
- 20.5" x 20.5"
Details
- Nominal Sq. Ft.
- 23.35
- Coverage
- 23.35
- Car Jack Approved
- Yes
- Chemical-Resistant
- Yes
- Colorfast
- Yes
- Gloss
- Semi-Gloss
- Interlock Style
- Hidden Interlock
- Material
- Flexible PVC
- Slip Resistant
- Yes
Features
- Car & Jack Approved
- Chemical Resistant
- Colorfast
- Easy to install, no adhesive needed.
- Withstands heavy loads.
- Slip-resistant.
- Stain, mold, mildew resistant, and odor-free.
- Interlocking system will connect with our Coin Flex Tiles new interlocking system.
Shipping & Returns
Ships between Apr 15 – Jul 12
Installation
Installation Instructions for Diamond Flex Tiles
Preparation
- Surface Cleaning:
- Ensure the subfloor is clean, dry, and free of debris, grease, oil, and other contaminants.
- Subfloor Suitability:
- Suitable for installation over concrete, wood, or any hard, flat surface.
- Acclimatization:
- Allow the Flex Nitro Tiles to acclimate in the installation area for at least 24 hours at room temperature.
Installation
- Planning Layout:
- Lay out the tiles in the desired pattern before snapping them together to ensure you are satisfied with the design.
- Plan your pattern ahead of time, especially if using multiple colors, to avoid mistakes.
- Connecting Tiles:
- Begin installation from one corner of the room and work your way out.
- Align the tiles so that the tabs of one tile fit into the loops of the next tile.
- Gently press down until you hear a click, indicating the tiles are locked together.
- Cutting to Fit:
- Trim the tiles to fit around edges and corners using a utility knife with a sharp blade and a straight edge.
- Leave a small gap (approximately 1/4 inch) around the edges to allow for expansion and contraction.
- Securing the Tiles:
- For smaller areas, the weight of the tiles may be sufficient to keep them in place.
- For larger areas or high-traffic zones, use double-sided tape or adhesive around the perimeter and seams for extra stability.
- Apply the adhesive according to the manufacturer’s instructions.
Post-Installation
- Rolling:
- Use a floor roller to ensure the tiles adhere properly and to remove any air bubbles.
- Initial Cleaning:
- After installation, clean the floor with a mild soap and water solution to remove any installation debris.
- Inspection:
- Inspect the installation to ensure all edges are secure and seams are properly sealed.
Maintenance
- Follow the regular cleaning and maintenance instructions to keep your Flex Nitro Tiles in optimal condition.
Contact Information
- Customer Service:
- For any issues or further assistance, please contact our dedicated Customer Service team.
Care & Maintenance
Maintenance Instructions for Flex Tiles
Regular Cleaning
- Sweeping or Vacuuming:
- Regularly sweep or vacuum the tiles to remove loose crumbs, dust, and debris.
- Damp Mopping:
- Occasionally damp mop the tiles using a mixture of mild soap and water.
- Recommended soaps: Dawn dish detergent or Tide laundry detergent.
Protecting Your Tiles
- Silicone Sealant Protection:
- Each tile is coated with a protectant silicone sealant.
- Tiles may become scuffed or scratched during installation or while moving large objects.
- Reducing Scratches and Scuffs:
- Use Armstrong’s Shine Keeper to help reduce the appearance of scratches and scuff marks.
Stain Prevention and Removal
- Street Tar and Light-Colored Tiles:
- Note: This is not a stain-proof product.
- Street tar can stain light-colored tiles. Use Purple Power cleaner to remedy this.
- Performance Tires and Light-Colored Tiles:
- Performance tires can cause staining on light-colored tiles.
- To remove tire marks, you might need to replace the affected tiles or use darker tiles to disguise the stains.
- If staining persists, contact our Customer Service team for assistance.
Contact Information
- Customer Service:
- For any issues or further assistance, please contact our dedicated Customer Service team at (877) 531-6471.
Warranty
Customer Questions & Answers
12 questions
I am in Arizona, how does your garage tiles hold up to extreme heat? Will my vehicle's tires stick to tiles?
Our Diamond Flex Tiles have been installed all over the country from the coldest parts of the North Dakota to the hottest parts here in Arizona. These tiles hold up very well in all climate types and will not get brittle in extreme cold or melt in extreme heat. These tiles are made from the same material that your water pipes in your home are made of, PVC. In extreme heat, your tires will not stick to the tiles. These tiles are made to expand and contract with the outside temperature. So, in extreme heat situations, your tiles will expand a bit. In extreme cold, they will contract.
Was this helpful?my garage floor is 70 yrs old and is uneven withbsmall ridges and divets. Does that effect your product much? The sample you send out how big is it so i coukd lay it in some of the worst area and see how it lays?
The sample size is small, not large enough to review over uneven subfloor. We'd recommend purchasing a full tile for a better indication of how the tile would lay on your floor. We would always recommend leveling out the concrete for best results.
Was this helpful?With the car parked in the garage, when the front tires are turned while the car is stationary, will the tile be pulled up or wrinkle or otherwise move?
That is possible and we do not advise turning your tires while parked on the tiles.
Was this helpful?Will the diamond flex tile shrink to show the seems and collect dirt to make the seems standout. Thanks
The tiles will not shrink that like. There may be expansion / contraction depending on the conditions, but it would be minimal.
Was this helpful?
Reviews
Customer photos
Showing 1–54 of 54 written reviews (57 ratings in total)
- 5 out of 5 starsLooks great and easy to install
I was able to do my 2 car garage on my own in one afternoon and it looks amazing
Anonymous ·
- 5 out of 5 starsGreat product for my garage
These tiles work great, look great and installation was simple. I would suggest using black wherever you have tires in contact for long periods of time. I started out with grey and the tires left marks that could not be cleaned off, I went to black and now you don't even see where the car is parked.
Bruce F. ·
12 of 12 found this helpful
- 4 out of 5 starsGreat Product - Be careful not to over purchase
I researched many products for my 20'x19 garge floor. I fInally decided on the diamond pattern 4.5mm rubber tiles. The customer service was excellent and highly recommend getting the samples first - it helped me pick the best pattern. The tiles arrived within 5 days and after contemplating where to start - I began in the corner and the installation was very simple. I bought a pair of heavy duty shears from Lowes and it cut through each tile easily. I got the black after the customer service rep warned my tire marks would show on the lighter colors. The only reason I'm giving it 4stars is after using the room calculator and also talking to the Rep - I ordered 184 tiles (5% overage they state). After completing the floor and also using numerous tiles for edge pieces, I have 6 extra boxes (48 extra tiles) - and could have saved a lot of money. So - I highly recommend the product but be cautious not to over order.
Anonymous ·
1 of 1 found this helpful
